Intelligent Switch System

Name: Intelligent Switch System
Brand: SAFEZONE AUTOMATIONS
Price: 8500.0 INR
Availability: InStock

Price 8500.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

Intelligent Switch System Specification

Components
Capacitive touch panel, wireless module, relay circuitry

Features
Smart touch panel, Wi-Fi/Bluetooth enabled, energy saving, remote operation, elegant glass panel

Sensors Specification
Capacitive touch sensing

Interface
Touch surface, wireless app connectivity

Usage
Residential and commercial buildings

Response Time
<30 ms (touch response)

IP Rating
IP20

Power Source
AC Mains

Display Type
Backlit touch screen panel

Power Supply
AC Powered

Operating Temperature
0C to 55C

Output
3-6 channel output for electrical appliances

Input
Standard wall input (AC)

Resolution
Not specified (touch interface, not graphical)

Product Type
Intelligent Switch System

Application
Switching, lighting control, smart home integration

Rated Voltage
220-240V AC

Supply Voltage
220-240V AC

Size
Standard modular fitting

Dimension (L*W*H)
86mm x 86mm x 10mm

Function
Touch control switch system for controlling lights and electrical appliances

Color
White (panel), Black (screen area)

Weight
Approx 200-350g

Thickness
6-10 mm (front panel)

Capacity
10A per channel (max)

Current Rating
10A

Frequency
50-60 Hz

Scene Support
Multiple programmable scenes

Panel Finish
Glossy anti-scratch surface

Safety Features
Overload and surge protection

Installation Type
Wall mount modular

Material
Tempered glass panel, fire-retardant ABS back housing

Standby Power Consumption
<0.5W

Compatibility
Works with Alexa, Google Home, and proprietary apps

Wireless Protocol
Wi-Fi & Bluetooth supported

Customization
Logo and channel icon customization available

About Intelligent Switch System

Smart Switch with Voice Control Supply and installation of a smart switch with voice-control functionality, enabling convenient operation of electrical appliances through mobile applications and compatible voice assistants. The switch shall support remote access, scheduling, automation features, and reliable wireless connectivity, providing enhanced convenience, energy efficiency, and modern smart-home integration.

Advanced Touch Control Technology

Utilizing cutting-edge capacitive touch sensing with a backlit, glossy panel, the Intelligent Switch System provides intuitive control for lighting and appliances. The sleek tempered glass design offers both elegance and robustness, fitting seamlessly into modern interiors.

Flexible Smart Home Integration

Supporting Wi-Fi and Bluetooth, this system is compatible with Amazon Alexa, Google Home, and proprietary applications, enabling convenient voice commands and mobile app operation. It offers enhanced flexibility for residential and commercial environments seeking efficient automation.

Reliable Safety and Energy Efficiency

With overload and surge protection integrated into each channel, as well as a fire-retardant ABS back housing, the switch ensures superior operational safety. Its low standby power consumption (less than 0.5W) contributes to energy savings for both homes and businesses.

FAQ's of Intelligent Switch System:

Q: How is the Intelligent Switch System installed in existing buildings?

A: The switch system is designed for wall mount modular fitting, adhering to standard sizes (86mm x 86mm x 10mm) and AC mains input, making it suitable for straightforward installation in most residential and commercial settings by qualified electricians.

Q: What wireless technologies does this switch support for remote operation?

A: This switch system supports both Wi-Fi and Bluetooth protocols, enabling remote control through mobile apps, as well as seamless integration with Alexa and Google Home platforms for hands-free voice operation.

Q: When can I use the programmable scene feature, and what are its benefits?

A: You can utilize the programmable scene feature anytime to automate multiple devices simultaneously according to your preferences-such as setting mood lighting or switching off all appliances with one touch-enhancing convenience and energy management.

Q: Where is customization possible in this system?

A: Customization options include adding your own logo and channel icons on the touch panel, making it ideal for branding in projects or easily identifying different switches for various electrical appliances.

Q: What safety features does the Intelligent Switch System offer?

A: Safety is ensured through overload and surge protection for every channel, combined with a fire-retardant ABS back housing. The tempered glass surface further enhances durability and user safety during daily operation.

Q: How can I benefit from smart home integration with this switch?

A: Smart home integration allows remote monitoring and control from anywhere, scene programming via app or voice assistants, energy saving through automated schedules, and improved convenience for managing up to six electrical channels simultaneously.

Q: What is the recommended usage environment for this switch system?

A: This switch is suitable for both residential and commercial buildings, with an operating temperature range of 0C to 55C and an IP20 rating-ideal for indoor lighting and electrical appliance control where smart automation is desired.
